AMS Titanium Alloy 8-1-1 ( 8Al-1Mo-1V) Bar and Rod

1.Titanium 8-1-1 (8Al-1Mo-1V) is a near alpha alloy offering good weld ability and with superior creep resistance at operating temperature up to 450°C. Alloy 8-1-1 has a relatively high tensile modulus to density ratio and is used primarily in engine applications such as forged compressor blades and disks.
2.Size: Φ7mm~Φ230mm;

Products Inquiry

CompanyName * :

Email * :

Name :

Tel :

Message :

Product Details

Titanium 8-1-1 (8Al-1Mo-1V) is a near alpha alloy offering good weldability and with superior creep resistance at operating temperature up to 450°C. Alloy 8-1-1 has a relatively high tensile modulus to density ratio and is used primarily in engine applications such as forged compressor blades and disks.

Standard Specification:

AMS-T-9047 8Al-1Mo-1v bar;

MIL-T-9047G 8Al-1Mo-1V bar;

Standard	Werkstoff No.	UNS
AMS Titanium Alloy 8-1-1 / 8Al-1Mo-1V	3.7134	R54810

Technical Data Sheet

Chemical Composition
Weight %	Ti	Al	Mo	V	C	Fe	N	O	H	Other
AMS Titanium Alloy 8-1-1 / 8Al-1Mo-1V	Balance	7.35~8.35	0.75~1.25	0.75~1.25	0.08	0.30	0.05	0.2	0.0150	0.4 Total Max.

Typical Mechanical Properties (Tensile Requirements)

Material

Tensile Strength, min

Yield Strength (0.2% Offset) min or range

Elongation in 4D,min%

eduction of Area

Min %

ksi

MPa

ksi

MPa

Titanium Alloy 8-1-1 / 8Al-1Mo-1V

130

896

120

827
