1.Titanium Alloy Grade 4 is “unalloyed” titanium offering improved strength, moderate ductility. The material is readily weldable.
2.This material is very corrosion resistant in highly oxidizing and mildly reducing environments.
3.Size: Φ0.1mm~Φ7mm;
Titanium Alloy Grade 4 is “unalloyed” titanium offering optimum ductility and cold formability. The material has high impact toughness and is readily weldable. The material is capable of deep drawing.
Standard Specification: ASTM B863, ASME SB863, ASTM F67, ISO, DIN AMS-T-9046 CP4 / AMS 4940;
Standard |
Werkstoff No. |
UNS |
Commercial Pure Titanium Grade4 |
3.7065 |
R50700 |
Technical Data Sheet
Chemical Composition |
||||||
Weight % |
Ti |
C |
Fe |
N |
O |
H |
Commercial Pure Titanium Grade4 |
Balance |
0.08 |
0.5 |
0.05 |
0.4 |
0.015 |
Typical Mechanical Properties (Tensile Requirements)
Material |
Tensile Strength, min |
Yield Strength (0.2% Offset) min or range |
Elongation in 4D,min% |
Reduction of Area Min % |
||
ksi |
MPa |
ksi |
MPa |
|||
Commercial Pure Titanium Grade4 |
80 |
550 |
70 |
483 |
15 |
25 |
