AMS Titanium Alloy Grade 6 / Ti-5Al-2.5Sn Sheet and Plate

AMS 4909 Sheet, Strip, Plate (EL1 grade)
AMS 4910 Sheet, Strip, Plate;
AMS-T- 9046 A-1 Sheet, Strip, Plate;
AMS-T-9046 A-2 (EL1) Sheet, Strip, Plate;
MIL-T-9046J A-1 Sheet, Strip, Plate;
MIL-T-9046H Type II Comp A Sheet, Strip, Plate;
MIL-T-9046H Type II Comp B Sheet, Strip, Plate;

Products Inquiry

Product Details

Titanium Ti5Al2.5Sn (Grade 6) is a high strength alloy which is most commonly used in airframe and jet engine applications. Titanium Ti5Al2.5Sn (Grade 6) has good weldability, stability and strength at elevated temperatures.

Standard Specification:

AMS 4909 Sheet, Strip, Plate (EL1 grade)

AMS 4910 Sheet, Strip, Plate;

AMS-T- 9046 A-1 Sheet, Strip, Plate;

AMS-T-9046 A-2 (EL1) Sheet, Strip, Plate;

MIL-T-9046J A-1 Sheet, Strip, Plate;

MIL-T-9046H Type II Comp A Sheet, Strip, Plate;

MIL-T-9046H Type II Comp B Sheet, Strip, Plate;



Standard

Werkstoff No.

UNS

Titanium Alloy Grade 6 / Ti-5Al-2.5Sn

3.7114

R54520



Technical Data Sheet

Chemical Composition

Weight %

Ti

Al

Sn

C

Fe

N

O

H

Other

Titanium Alloy Grade 6 / Ti-5Al-2.5Sn

Balance

4.0~6.0

2.0~3.0

0.1

0.05

0.05

0.2

0.020

0.4 Total Max.



Typical Mechanical Properties (Tensile Requirements)

Material

Tensile Strength, min

Yield Strength (0.2% Offset) min or range

Elongation in 4D,min%

ksi

MPa

ksi

MPa

Titanium Alloy Grade 6 / Ti-5Al-2.5Sn

120

830

115

795

10
