Aluminum and aluminum Tubes and Pipes

GOOLEE stocks 6061, 6063, 5083, and 5086 alloys in extruded aluminum piping in the tempers of T6, T6511, O, H32, and T52. We also carry a drawn aluminum pipe product in 6061 alloy with a T6 temper.
Due to the diversity of its properties, extruded aluminum tube is used in a variety of industries markets.
Size:Φ6~Φ626×Wall Thickness1mm~Wall Thickness50mm;

Products Inquiry

CompanyName * :

Email * :

Name :

Tel :

Message :

Product Details

Aluminum and aluminum Tubes and Pipes chemical composition

Aluminum Grade	Typical Chemical Composition %
Aluminum 5086	Weight %	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Each	Total
	Minimum	~	~	~	0.2	3.5	0.05	~	~	~	~
	Maximum	0.40	0.50	0.10	0.70	4.5	0.25	0.25	0.15	0.05	0.15
	Remainder Aluminum
	Typical Mechanical Properties
	Temper	Tensile
	H32	Ultimate/Min				Yield/Min
		KSI				KSI
		42				30
Aluminum 6063	Weight %	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Each	Total
	Minimum	0.02	~	~		0.45	~	~	~	~	~
	Maximum	0.60	0.35	0.10	0.10	0.90	0.01	0.1	0.1	0.05	0.15
	Remainder Aluminum
	Typical Mechanical Properties
	Temper	Tensile
	T6	Ultimate/Min				Yield/Min
		MPa				MPa
		240				215
Aluminum Grade	Typical Chemical Composition %
Aluminum 6061	Weight %	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Each	Total
	Minimum	0.40	~	0.15	~	0.80	0.04	~	~	~	~
	Maximum	0.80	0.70	0.40	0.15	1.20	0.35	0.25	0.15	0.05	0.15
	Remainder Aluminum
	Typical Mechanical Properties
	Temper	Tensile
	O	Ultimate/Min				Yield/Min
		MPa				MPa
		124				55
Aluminum 5083	Weight %	Si	Fe	Cu	Mn	Mg	Cr	Zn	Ti	Each	Total
	Minimum	~	~	~	0.40	4.0	0.05	~	~	~	~
	Maximum	0.40	0.40	0.10	1.0	4.9	0.25	0.25	0.15	0.05	0.15
	Remainder Aluminum
	Typical Mechanical Properties
	Temper	Tensile
	O	Ultimate/Min				Yield/Min
		MPa				MPa
		310				125
