Niobium and Niobium Alloys Sheet and Plate

Niobium also occupies an important position in surgical medicine. It can not only be used to manufacture medical devices, but also a good "biocompatible material" because it has excellent corrosion resistance and will not interact with various liquids in the human body. The substance acts, and almost does not damage the organism's body tissues. It can be adapted to any sterilization method, so it can be combined with organic tissues for a long time and stay in the human body harmlessly.

Products Inquiry

CompanyName * :

Email * :

Name :

Tel :

Message :

Product Details

1. Specification: RO4200-1，RO4210-2

2. Standard:ASTM B393-18

3. Size

Type	Thickness(mm)	Width(mm)	Length（mm）
Niobium Foil	0.03-0.09	30-150	<2000
Niobium Sheet	0.1-0.5	30-600	30-2000
Niobium Plate	0.5-10	50-1000	50-2000

Chemical Composition

Content %
Niobium Grade	Main Composition	The impurity content is not more than
Niobium Grade	Nb	Fe	Si	Ni	W	Mo	Ti	Ta	O	C	H	N
Nb1	Balance	0.004	0.004	0.002	0.005	0.005	0.002	0.07	0.015	0.004	0.0015	0.003
Nb2	Balance	0.01	0.01	0.005	0.02	0.01	0.004	0.10	0.02	0.01	0.0015	0.008
If the user has special requirements, the two parties specifically negotiate
